Understanding Cabin Heating: Engine Cars vs. EVs

When winter arrives, stepping into a warm car after braving the cold is a comforting experience. But have you ever wondered how your car’s cabin heating system works? Whether you’re driving a traditional internal combustion engine (ICE) vehicle or a modern electric vehicle (EV), the heating mechanisms differ significantly. From harnessing waste heat in engine cars to utilising advanced thermal management systems in EVs, let’s explore the fascinating world of cabin heating.

The Role of the HVAC System

Before diving into the specifics of cabin heating, it’s essential to understand the HVAC system—which stands for heating, ventilation, and air conditioning. This system is responsible for regulating the temperature inside the vehicle, ensuring comfort in both cold and hot weather.

The HVAC system consists of key components such as:

• Blower motor – Pushes air through the vents
• Evaporator – Cools the air when the air conditioning is running
• Heater core – A radiator-like component that helps warm up the cabin

Although the basic structure of the HVAC system remains similar, the heating mechanism varies between engine-powered vehicles and electric cars.

How Cabin Heating Works in Internal Combustion Engine Cars

Traditional vehicles with internal combustion engines generate heat as a byproduct of fuel combustion. This waste heat is cleverly repurposed to warm the cabin using the following process:

1. Combustion Heat Generation – When fuel burns in the engine’s combustion chamber, it produces immense heat. To prevent overheating, the engine block and cylinder head are surrounded by coolant jackets, which circulate coolant to absorb this heat.
2. Coolant Circulation – A water pump, driven by the engine’s crankshaft, circulates the coolant through the engine and into the radiator, where it cools down.
3. Thermostat Regulation – A thermostat valve helps control the coolant’s flow. When the engine is cold, the thermostat remains closed, allowing coolant to circulate only within the engine and heater core, helping the vehicle warm up faster. Once the engine reaches optimal operating temperature (around 90°C), the thermostat opens, sending coolant to the radiator for cooling.
4. Heat Transfer via the Heater Core – A portion of the hot coolant is diverted to the heater core, located inside the dashboard. The heater core, similar to a small radiator, transfers heat from the coolant to the surrounding air.
5. Blower Motor and Air Distribution – A blower fan pushes air over the heater core’s heated fins, directing warm air through the vehicle’s vents. The climate control system adjusts the temperature and airflow by blending cold air from the evaporator or fully opening the heater core’s warm airflow.

This system is efficient and effective in ICE vehicles because it utilises waste heat from the engine. As long as the engine is running, there is no additional energy cost for heating.

Cabin Heating in Electric Vehicles: A Different Challenge

Unlike ICE cars, electric vehicles do not have an engine to generate excess heat. Instead, they must rely on dedicated electrically powered heating systems to warm the cabin. The two primary solutions used in EVs are:

1. Positive Temperature Coefficient (PTC) Heaters
2. Heat Pump Systems (with Tesla’s Octovalve Technology)

1. PTC Heaters: The Resistive Heating Approach

PTC (Positive Temperature Coefficient) heaters function similarly to household electric heaters. These devices use resistive heating elements, often made from materials like nichrome, which convert electrical energy into heat when current flows through them.

The key characteristics of PTC heaters are:

• They automatically regulate temperature – as the material heats up, its resistance increases, limiting power consumption.
• Positioned within the airflow path of the HVAC system, the PTC heater warms the air before it enters the cabin.

Drawbacks of PTC Heaters:
While effective, PTC heaters consume significant power, drawing between 3 kW to 5 kW when first turned on. Once the desired temperature is reached, power consumption drops to around 1 kW to 2 kW. However, this still reduces driving range.

For example, an EV with a 250-mile range can lose 25 to 75 miles (10-30%) when using a PTC heater in cold conditions.

2. Heat Pump Systems: A More Efficient Alternative

To reduce energy consumption, modern EVs, including Tesla’s newer models, utilise heat pump systems instead of PTC heaters.

How Heat Pumps Work

A heat pump functions similarly to an air conditioner but in reverse. Instead of generating heat, it absorbs heat from the outside air—even in cold conditions—and transfers it into the cabin.

1. Heat Absorption – The evaporator absorbs heat from the outside air, turning the refrigerant from liquid to gas.
2. Compression & Temperature Increase – The gas flows to an electric compressor, which compresses it, raising its temperature.
3. Heat Release – The heated gas moves to the condenser, which releases heat into the cabin air, warming the interior efficiently.

Because Earth’s atmosphere never reaches absolute zero (0 Kelvin), there is always some heat available—even in freezing conditions. This makes heat pumps a more energy-efficient solution.

Tesla’s Octovalve: Next-Level Thermal Management

Tesla has taken heat pump technology further with its Octovalve system, a sophisticated thermal management component designed to optimise heat flow.

How the Octovalve Works

• The Octovalve has eight ports that direct coolant between multiple vehicle components, including the battery pack, motor drive unit, power electronics, and radiator.
• At its core is a rotary valve that dynamically opens and closes pathways to manage heat transfer.
• It works alongside a Super Manifold, which distributes coolant efficiently across different circuits.

By leveraging waste heat from the battery and other components, the Octovalve system enhances efficiency while reducing power consumption.

Energy Consumption Comparison: PTC vs. Heat Pump

• PTC Heaters – Require 3 kW to 7 kW to maintain cabin warmth.
• Heat Pumps (Octovalve) – Use only 1 kW to 2 kW, reducing energy drain on the battery and extending driving range.

This energy-saving advantage is why Tesla, Hyundai, and other EV manufacturers are increasingly adopting heat pump technology over traditional PTC heaters.

Conclusion: Choosing the Right Cabin Heating System

• Internal Combustion Engine Cars – Efficiently use waste heat from the engine, making their cabin heating system highly effective with minimal energy cost.
• Electric Vehicles – Require dedicated heating systems, with PTC heaters consuming more power and heat pumps providing a more energy-efficient solution.
• Tesla’s Octovalve – A cutting-edge thermal management system that further optimises heat distribution and energy savings in EVs.

As EV adoption grows, the demand for efficient cabin heating systems will continue to shape future innovations. Whether through advanced heat pumps, intelligent thermal routing, or alternative heating methods, the focus remains on maximising energy efficiency while ensuring driver comfort.
